Transfer learning applied on the unsplash data using alexnet pretrained network

Transfer learning using the MATLAB pre-trained deep learning networks can be implemented quite easily to achieve great results.

Transfer learning using the pre-trained deep learning networks from MATLAB can be easily implemented to achieve fast and impressive results

I obtained the image data from Unsplash. I downloaded 42 cat images, 46 dog images, and 35 horse images for the input into the pre-trained Alexnet model in MATLAB. For details about the Alexnet network in MATLAB, see its documentation.

Photo by JJ Ying on Unsplash
Photo by JJ Ying on Unsplash

Alexnet

AlexNet is a convolutional neural network that is 8 layers deep. The MATLAB has a pre-trained version of the network trained on more than a million images from the ImageNet database. The pre-trained network can classify images into 1000 predefined object categories.

The training for the 1000 object categories on a million images has made the network learn rich feature representations for a wide range of images.

Transfer learning applied on the Unsplash data using alexnet pre-trained network

Installation

You can check the installation of alexnet by typing

alexnet

at the command line. If it’s not installed then it will prompt a link to the required support package in the Add-On Explorer. Simply, follow the link.

Why Transfer Learning?

Transfer learning has become popular in deep learning applications because of its speed and easy implementation. One can take a pre-trained network and use it as a starting point to learn a new task. This quickly transfers learned features to a new task using a smaller number of training images.

Data

I obtained the three categories of images from the Unsplash website. Unsplash provides millions of high-quality free images. I obtained the images for cats, dogs, and horses. There is no specific reason for using these categories but using cats and dogs has become standard for testing any model as it provides sufficient robustness.

I saved the data into three subfolders folders labeled with cats, dogs, and horses under the folder unsplashData. I kept the zipped data in the folder containing the script.

Prepare data

The first thing we do is to unzip the data using the unzip command. Then we automatically label the images based on folder names and store the data as an ImageDatastore object.

clear; close; clc;

%% Unzip and load the new images as an image datastore
filename = 'unsplashData';
unzip(strcat(filename,'.zip'));

% imageDatastore automatically labels the images based on folder names and stores the data as an ImageDatastore object
imds = imageDatastore(filename, ...
    'IncludeSubfolders',true, ...
    'LabelSource','foldernames');

Divide the data into training and validation data sets

We use 70% of the randomly selected images for training and 30% for validation.

[imdsTrain,imdsValidation] = splitEachLabel(imds,0.7,'randomized');

Visualize the loaded images

We plot the 16 randomly selected data.

visualize = 1;
if visualize==1
    numTrainImages = numel(imdsTrain.Labels);
    idx = randperm(numTrainImages,16);
    fig1 = figure;
    for i = 1:16
        subplot(4,4,i)
        I = readimage(imdsTrain,idx(i));
        imshow(I)
    end
    print(fig1,strcat(filename,'input-data-selected'),'-djpeg')
end
Image by author
Image by author

Load Pretrained Network

net = alexnet;
inputSize = net.Layers(1).InputSize

To analyze the layers of the alexnet network.

inspect_network=0;
if inspect_network==1
    analyzeNetwork(net)
end
Image by author
Image by author

Replace the final three layers

We extract all layers, except the last three, from the pre-trained network. One can increase the WeightLearnRateFactor and BiasLearnRateFactor values of the fully connected layer to learn faster in the new layers than in the transferred layers

layersTransfer = net.Layers(1:end-3);

numClasses = numel(categories(imdsTrain.Labels)) %the number of classes in the new data

layers = [
    layersTransfer
    fullyConnectedLayer(numClasses,'WeightLearnRateFactor',20,'BiasLearnRateFactor',20)
    softmaxLayer
    classificationLayer];

Use an augmented image datastore to automatically resize the training images

The alexnet network has been designed to work on the images of fixed dimensions (227-by-227-by-3). We follow the standard operations to augment the training images – randomly flip the training images along the vertical axis, randomly translate them up to 30 pixels horizontally and vertically. Data augmentation is necessary to prevent the network from overfitting and memorizing the exact details of the training images.

pixelRange = [-30 30];
imageAugmenter = imageDataAugmenter( ...
    'RandXReflection',true, ... %randomly flip the training images along the vertical axis
    'RandXTranslation',pixelRange, ... %randomly translate them up to 30 pixels horizontally and vertically
    'RandYTranslation',pixelRange);

augimdsTrain = augmentedImageDatastore(inputSize(1:2),imdsTrain, ...
    'DataAugmentation',imageAugmenter);

% automatically resize the validation images without performing further data augmentation
augimdsValidation = augmentedImageDatastore(inputSize(1:2),imdsValidation);

Fine-tune the training options

The goal of applying transfer learning is to keep the features from the early layers of the pre-trained network (the transferred layer weights).

options = trainingOptions('sgdm', ...
    'MiniBatchSize',10, ... %when performing transfer learning, you do not need to train for as many epochs
    'MaxEpochs',6, ...
    'InitialLearnRate',1e-4, ... %slow down learning in the transferred layers ( fast learning only in the new layers and slower learning in the other layers)
    'Shuffle','every-epoch', ...
    'ValidationData',augimdsValidation, ...
    'ValidationFrequency',3, ...
    'Verbose',false, ...
    'Plots','training-progress', ...
    'ExecutionEnvironment','auto'); %Hardware resource for training network - auto, cpu, gpu, multi-gpu, parallel

Train the network

We train the network consisting of the transferred and new layers.

netTransfer = trainNetwork(augimdsTrain,layers,options); %By default, trainNetwork uses a GPU if one is available

Classify Validation Images

[YPred,scores] = classify(netTransfer,augimdsValidation); %classify using the fine-tuned network

We display four sample validation images with their predicted labels.

classify_visualize = 1;
if classify_visualize==1
    idx = randperm(numel(imdsValidation.Files),4);
    fig = figure;
    for i = 1:4
        subplot(2,2,i)
        I = readimage(imdsValidation,idx(i));
        imshow(I)
        label = YPred(idx(i));
        title(string(label));
    end
    print(fig,strcat(filename,'classification-result'),'-djpeg')
end
Image by author
Image by author

Classification accuracy

Classification accuracy gives the fraction of labels that the network predicts correctly.

YValidation = imdsValidation.Labels;
accuracy = mean(YPred == YValidation)
% accuracy = 0.9189

Conclusions

I used the pre-trained Alexnet network from Matlab to fine-tune it with the Unsplash data. However, it has the potential for any classification problems with the image data. We should also explore several other pre-trained networks provided by MATLAB such as squeezenet, resnet18, googlenet, etc to achieve better accuracy. The accuracy depends highly on the data quantity, quality, and model parameters such as the number of layers.


Originally published at https://www.earthinversion.com on April 25, 2021.
