Quick Recommendation-Based Data Exploration with Lux

Explore your data easily with one-liner recommendation-based data exploration

GIF Created by Author
GIF Created by Author

As a Data Scientist, data exploration, or EDA, is our everyday work and the thing we get paid to do. There is no other skill more important to a data scientist than the data exploration skill (in my opinion). While it is important, we know that the process is a hassle and sometimes a time-exhauster. Moreover, a lot of times, we do not know where to start exploring the data.

Take the example of the mpg dataset below:

import pandas as pd
import seaborn as sns
mpg = sns.load_dataset('mpg')
mpg.head()
Image created by Author
Image created by Author

Where do we start exploring data if we are not an expert in the car field, like me? In this case, we can try the recommender-based EDA using the lux package.

If you want to check out another open-source EDA package, you can check out my article here as well.

Data Frame EDA Packages Comparison: Pandas Profiling, Sweetviz, and PandasGUI

Anyway, let’s see how we can use the lux package to help us explore our data.


Lux

Lux is an open-source package in Python designed to help us explore data more intelligently with their recommendation. The package was aimed at people who did not know where to start when exploring the data.

Let’s start by installing the package.

pip install lux-api

When you have finished installing the package, we need to enable the lux widget in our jupyter notebook.

jupyter nbextension install --py luxwidget
jupyter nbextension enable --py luxwidget

Now, let’s try using the Lux package to explore our data. First, we need to import the package to automatically setting up the widget in our notebook.

import lux

Just like that, we already set up the Lux package to be integrated with the Pandas Data Frame. Next, let’s try to open any of our Data Frame; let’s try with the previously used mpg dataset.

Image created by the Author
Image created by the Author

With the Lux package, we can see a new button called "Toggle Pandas/Lux" we could press. Try to press that button.


Lux Basic Visualization

Image created by Author
Image created by Author

Automatically, a set of visualization is created based on our dataset. in default, there are three visualization categories created; Correlation, Distribution, and Occurrence.

The Correlation tab comprised all the numerical relationships between two variables, which were visualized by the scatter plot. You can see the example in the above picture.

The Distribution tab shows a single numerical variable where the variables are visualized using a histogram plot. You can see the example in the below picture.

Image created by the Author
Image created by the Author

The Occurrence tab shows the count plot of the categorical variable. It shows each class frequency in the categorical variable, just like in the picture below.

Image created by the Author
Image created by the Author

Lux Recommendation-Based Visualization

In addition to data frame visualizations, we can specify in Lux the attributes and values we are interested in for Lux to guide our data exploration’s potential next steps.

Ler’s say that I am interested in both ‘mpg‘ and ‘horsepower‘ attributes because I know it was related. We can specify it both in the Lux package to guide us with the .intent method, just like the line below.

mpg.intent = ['mpg', 'horsepower']
Image created by the Author
Image created by the Author

With the intent set to our data frame, the Lux package gives us the visualization recommendation. There are three different options we can see; Enhance, Filter, and Generalize.

The Enhance tab shows the visualization recommendation by adding additional variables to our current intent. Essentially it shows how another variable affecting the variables we are interested in. You can see the example in the above picture.

The Filter tab **** adds a filter to the current intent you have set; this is done while keeping the attributes (on the X and Y axes) fixed. The recommendation would show us the relationship between our variable filtered from another variable. You can see from the image below that the scatter plot is filtered by the model_year variable for each class the column has.

Image created by the Author
Image created by the Author

The generalize tab removes an attribute to display a more general trend, showing the attribute’s distributions. The purpose is to focus on the current attribute we are interested in.

You could try a variable combination between numerical and categorical as well. Although the maximum variables for the intent, you can specify is three variables. Nevertheless, it is enough for you to explore the data easily.


Lux exporting visualization

If you want to separate one of the visualization charts into another variable, you could do that in Lux. Let’s take a look at the image below.

Image created by Author
Image created by Author

We only need to click on our intended chart from the image above until they show the tick mark. After that, click on the export button (the one that I gave a red circle). With this, we are already successfully exporting the chart.

So, where to access the chart? The exported chart is actually stored in our own data frame variable. Let’s try to access it then.

#The visualization is stored in the .exported attribute we could access any time
vis = mpg.exported[0]
vis
Image created by the Author
Image created by the Author

With that, we have already stored our plot to a different variable.


Conclusion

Lux is a recommendation-based system EDA to help us quickly get around our data. The package helps us by giving us all the possible data combinations and exploring the data based on our own intention.
