In this tutorial we will explore the Davies-Bouldin index and its application to K-Means clustering evaluation in Python.
Table of Contents
- Introduction
- Davies-Bouldin Index
- Step 1: Calculate intra-cluster dispersion
- Step 2: Calculate separation measure
- Step 3: Calculate similarity between clusters
- Step 4: Find most similar cluster for each cluster i
- Step 5: Calculate Davies-Bouldin Index
- Davies-Bouldin Index example in Python
- Conclusion
Introduction
The Davies-Bouldin index (DBI) is one of the Clustering algorithms evaluation measures. It is most commonly used to evaluate the goodness of split by a K-Means clustering algorithm for a given number of clusters.
In a few words, the score (DBI) is calculated as the average similarity of each cluster with a cluster most similar to it. The lower the average similarity is, the better the clusters are separated and the better is the result of the clustering performed.
In the next section the process of calculating the DBI is described in detail with a few examples.
Davies-Bouldin Index
The research on cluster separation measure was published back in 1979. The material presented describes a measurement of similarity between clusters as a function of intra-cluster dispersion and separation between the clusters.
In this part we will go through each step of the calculations and provide meaningful illustrative examples to help better understand the formulas.
Step 1: Calculate intra-cluster dispersion
Consider the following equation defined by Davies, D., & Bouldin, D. (1979) that calculates the dispersion of cluster i:

where: i : particular identified cluster T_i : number of vectors (observations) in cluster i X_j : j-th vector (observation) in cluster i A_i : centroid of cluster i
Basically, to get the intra-cluster dispersion, we calculate the average distance between each observation within the cluster and its centroid.
Note: usually the value q is set to 2 (q = 2), which calculates the Euclidean distance between the centroid of the cluster and each individual cluster vector (observation).

Assume the K-Means clustering that was performed on some dataset generated three clusters. Using the above formula, the intra-cluster dispersion would be calculated for each of the clusters and we will have values for _S1, _S2, and _S3.
Step 2: Calculate separation measure
Consider the following equation defined by Davies, D., & Bouldin, D. (1979) that calculates the separation between clusters i and j:

where: a_{ki} : k-th component of n-dimensional centroid _Ai a_{kj} : k-th component of n-dimensional centroid _Aj N : total number of clusters
The above formula can also be written as:

Note: when p is set to 2 (p = 2), the above formula calculates the Euclidean distance between the centroids of clusters i and j.

Continue to assume that we are working with three clusters. Using the above formula, we will compute the separation measure for each possible combination of two clusters: M{11}_, M{12}_, M{13}_, M{21}_, M{22}_, M{23}_, M{31}_, M{32}_, and M{33}_.
Of course we also have M{12}_ = M{21}_, M{13}_ = M{31}_, and M{23}_ = M{32}_.
Step 3: Calculate similarity between clusters
Consider the following equation defined by Davies, D., & Bouldin, D. (1979) that calculates the similarity between clusters i and j:

where: S_i : intra-cluster dispersion of cluster i S_j : intra-cluster dispersion of cluster j M_{ij} : distance between centroids of clusters i and j
Basically here we are computing similarity between clusters as a sum of two intra-cluster dispersions divided by the separation measure. The larger R{ij}_ is, the more similar clusters i and j are. You can probably already tell that the best possible case is when these number overall are as low as possible.
Similarly to the logic in Step 2, continue to assume that we are working with three clusters. Using the above formula, we will compute the similarity for each possible combination of two clusters: R{11}_, R{12}_, R{13}_, R{21}_, R{22}_, R{23}_, R{31}_, R{32}_, and R{33}_.
Here, R{11}_ = R{22}_ = R{12}_ are the similarities of each cluster to itself. And we also have R{12}_ = R{21}_, R{13}_ = R{31}_, and R{23}_ = R{32}_.
Step 4: Find most similar cluster for each cluster i
Davies, D., & Bouldin, D. (1979) define:

having: i ≠ j
For each cluster i we find the highest ratio from all R{ij}_ calculated.
For example, for cluster i = 1, we calculated R{11}_, R{12}_, and R{13}_. Continue with R{12}_ and R{13}_ (since R{11}_ doesn’t satisfy the constraint i ≠ j, and it makes no sense to compare the cluster with itself).
Now, having R{12}_ (which is similarity between clusters 1 and 2) and R{13}_ (which is similarity between clusters 1 and 3). From these two measures, we would pick the largest one and refer to the maximum measure as R{1}_. Following the same logic we will find R{2}_ and R{3}_.
Step 5: Calculate the Davies-Bouldin Index
Calculate the Davies-Bouldin index as:

which is simply the average of the similarity measures of each cluster with a cluster most similar to it.
Note: the best choice for clusters is where the average similarity is minimized, therefore a smaller R-bar represents better defined clusters.
Davies-Bouldin Index Example in Python
In this section we will through an example of calculating the Davis-Bouldin index for a K-Means clustering algorithm in Python.
First, import the dependencies:
You can use any data with the code below. For simplicity we will use the built in Iris dataset, specifically the first two features: "sepal width" and "sepal length":
Let’s start with K-Means target of 3 clusters:
And check the Davies-Bouldin index for the above results:
You should see the resulting score: 0.7675522686571647 or approximately 0.77.
To put in perspective how the clusters look , let’s visualize them:
We should see the following 3 clusters:

Looks like some clusters are better defined than others.
So far we only computed the Davies-Bouldin index for 3 clusters. This measure can be used similarly to the Elbow Method, to help identify an optimal number of clusters.
We can run the calculation for any number of clusters greater or equal to 2. Let’s try up to 10 clusters:
and visualize it:

While in this example the measures are very close to each other, we can still observe that choosing 3 clusters minimizes the similarity measure.
Conclusion
In this article we discussed how to calculate the Davies-Bouldin index for clustering Evaluation in Python using sklearn library.
Feel free to leave comments below if you have any questions or have suggestions for some edits and check out more of my Python Programming articles.
References: Davies, D., & Bouldin, D. (1979). A Cluster Separation Measure. IEEE Transactions on Pattern Analysis and Machine Intelligence, PAMI-1(2), 224–227. https://doi.org/10.1109/TPAMI.1979.4766909
