Data Visualization in Python like in R’s ggplot2

A step-by-step tutorial how create a basic chart up to a publication ready dataviz chart

TUTORIAL – PYTHON – DATA VISUALIZATION

Photo by faaiq ackmerd from Pexels
Photo by faaiq ackmerd from Pexels

If you love plotting your data with R’s ggplot2 but you are bound to use Python, the plotnine package is worth to look into as an alternative to matplotlib. In this post I show you how to get started with plotnine for productive output.

If you want to follow along please find the whole script on GitHub:

scheithauer/python-plotnine

ggplot2

ggplot2 is a system for declaratively creating graphics, based on The Grammar of Graphics. You provide the data, tell ggplot2 how to map variables to aesthetics, what graphical primitives to use, and it takes care of the details. Source: http://ggplot2.tidyverse.org/

ggplot output; http://ggplot2.tidyverse.org/reference/figures/README-example-1.png
ggplot output; http://ggplot2.tidyverse.org/reference/figures/README-example-1.png

plotnine as an alternative to python’s matplotlib

In my experience the advantage of ggplot2 is the implementation of the grammar of graphics.

plotnine is a Grammar of Graphics for Python by Hassan Kibirige and brings the same advantages to python: Less coding and easy understanding (declarative paradigm).

Installing plotnine

# Using pip
$ pip install plotnine         # 1. should be sufficient for most
$ pip install 'plotnine[all]'  # 2. includes extra/optional packages

# Or using conda
$ conda install -c conda-forge plotnine

Data for visualizations

I used the craft-beers-dataset from Jean-Nicholas Hould. It contains information about 2,410 US craft beers. The information includes:

  • abv – The alcoholic content by volume with 0 being no alcohol and 1 being pure alcohol
  • ibu – International bittering units, which describe how bitter a drink is.
  • name – Name of the beer.
  • style – Beer style (lager, ale, IPA, etc.)
  • brewery_id – Unique identifier for brewery that produces this beer
  • ounces – Size of beer in ounces.
Data set example entries
Data set example entries

Install necessary libs

import pandas as pd
import numpy as np
from plotnine import *

Define useful constants

c_remote_data ='https://raw.githubusercontent.com/nickhould/craft-beers-dataset/master/data/processed/beers.csv'
c_col = ["#2f4858", "#f6ae2d", "#f26419",
         "#33658a", "#55dde0", "#2f4858",
         "#2f4858", "#f6ae2d", "#f26419",
         "#33658a", "#55dde0", "#2f4858"]

Useful functions

def labels(from_, to_, step_):
    return pd.Series(np.arange(from_, to_ + step_, step_)).apply(lambda x: '{:,}'.format(x)).tolist()
def breaks(from_, to_, step_):
    return pd.Series(np.arange(from_, to_ + step_, step_)).tolist()

Read data and set index

data = pd.read_csv(c_remote_data)
data = (
    data.filter([
        'abv',
        'ibu',
        'id',
        'name',
        'style',
        'brewery_id',
        'ounces'
    ]).
    set_index('id')
)

Histogram

Initial

fig = (
    ggplot(data.dropna(subset = ['abv'])) +
    geom_histogram(aes(x = 'abv'))
)

Adding color

fig = (
    ggplot(data.dropna(subset = ['abv'])) +
    geom_histogram(
        aes(x = 'abv'),
        fill = c_col[0], color = 'black'
    )
)

Adding labels

fig = (
    ggplot(data.dropna(subset = ['abv'])) +
    geom_histogram(
        aes(x = 'abv'),
        fill = c_col[0], color = 'black'
    ) +
    labs(
        title ='Distribution of The alcoholic content by volume (abv)',
        x = 'abv - The alcoholic content by volume',
        y = 'Count',
    )
)

Set the axes scaling

fig = (
    ggplot(data.dropna(subset = ['abv'])) +
    geom_histogram(
        aes(x = 'abv'),
        fill = c_col[0], color = 'black'
    ) +
    labs(
        title ='Distribution of The alcoholic content by volume (abv)',
        x = 'abv - The alcoholic content by volume',
        y = 'Count',
    ) +
    scale_x_continuous(
        limits = (0, 0.14),
        labels = labels(0, 0.14, 0.02),
        breaks = breaks(0, 0.14, 0.02)
    ) +
    scale_y_continuous(
        limits = (0, 350),
        labels = labels(0, 350, 50),
        breaks = breaks(0, 350, 50)
    )
)

Apply one of the available themes

theme_set(
    theme_538()
) # one time call

Change some theme features

theme_set(
    theme_538() +
    theme(
        figure_size = (8, 4),
        text = element_text(
            size = 8,
            color = 'black',
            family = 'Arial'
        ),
        plot_title = element_text(
            color = 'black',
            family = 'Arial',
            weight = 'bold',
            size = 12
        ),
        axis_title = element_text(
            color = 'black',
            family = 'Arial',
            weight = 'bold',
            size = 6
        ),
    )
)

Add some statistics

fig = (
    ggplot(data.dropna(subset = ['abv'])) +
    geom_histogram(
        aes(x = 'abv'),
        fill = c_col[0], color = 'black'
    ) +
    labs(
        title ='Distribution of The alcoholic content by volume (abv)',
        x = 'abv - The alcoholic content by volume (median = dashed line; mean = solid line)',
        y = 'Count',
    ) +
    scale_x_continuous(
        limits = (0, 0.14),
        labels = labels(0, 0.14, 0.02),
        breaks = breaks(0, 0.14, 0.02)
    ) +
    scale_y_continuous(
        limits = (0, 350),
        labels = labels(0, 350, 50),
        breaks = breaks(0, 350, 50)
    ) +
    geom_vline(aes(xintercept = data.abv.mean()), color = 'gray') +
    geom_vline(aes(xintercept = data.abv.median()), linetype = 'dashed', color = 'gray')
)

Faceting

fig = (
    ggplot(data.dropna(subset = ['abv', 'style'])[data['style'].dropna().str.contains('American')]) +
    geom_histogram(
        aes(x = 'abv'),
        fill = c_col[0], color = 'black'
    ) +
    labs(
        title ='Distribution of The alcoholic content by volume (abv)',
        x = 'abv - The alcoholic content by volume',
        y = 'Count',
    ) +
    scale_x_continuous(
        limits = (0, 0.14),
        labels = labels(0, 0.14, 0.07),
        breaks = breaks(0, 0.14, 0.07)
    ) +
    scale_y_continuous(
        limits = (0, 300),
        labels = labels(0, 300, 100),
        breaks = breaks(0, 300, 100)
    ) +
    theme(figure_size = (8, 12)) +
    facet_wrap('~style', ncol = 4)
)

Scatterplots

Initial

fig = (
    ggplot(data.dropna(subset = ['abv'])) +
    geom_point(
        aes(x = 'abv',
            y = 'ibu'),
        fill = c_col[0], color = 'black'
    ) +
    labs(
        title ='Relationship between alcoholic content (abv) and int. bittering untis (ibu)',
        x = 'abv - The alcoholic content by volume',
        y = 'ibu - International bittering units',
    ) +
    scale_x_continuous(
        limits = (0, 0.14),
        labels = labels(0, 0.14, 0.02),
        breaks = breaks(0, 0.14, 0.02)
    )  +
    scale_y_continuous(
        limits = (0, 150),
        labels = labels(0, 150, 30),
        breaks = breaks(0, 150, 30)
    )
)

Changing point sizes to a variable

fig = (
    ggplot(data.dropna(subset = ['abv'])) +
    geom_point(
        aes(x = 'abv',
            y = 'ibu',
            size = 'ounces'),
        fill = c_col[0], color = 'black'
    ) +
    labs(
        title ='Relationship between alcoholic content (abv) and int. bittering untis (ibu)',
        x = 'abv - The alcoholic content by volume',
        y = 'ibu - International bittering units',
    ) +
    scale_x_continuous(
        limits = (0, 0.14),
        labels = labels(0, 0.14, 0.02),
        breaks = breaks(0, 0.14, 0.02)
    )  +
    scale_y_continuous(
        limits = (0, 150),
        labels = labels(0, 150, 30),
        breaks = breaks(0, 150, 30)
    )
)

Changing point color to a variable

data['ounces_str'] = data['ounces']
data['ounces_str'] = data['ounces_str'].apply(str)
fig = (
    ggplot(data.dropna(subset = ['abv'])) +
    geom_point(
        aes(x = 'abv',
            y = 'ibu',
            fill = 'ounces_str'),
        alpha = 0.5,
        color = 'black'
    ) +
    labs(
        title ='Relationship between alcoholic content (abv) and int. bittering untis (ibu)',
        x = 'abv - The alcoholic content by volume',
        y = 'ibu - International bittering units',
    ) +
    scale_fill_manual(
        name = 'Ounces',
        values = c_col) +
    scale_x_continuous(
        limits = (0, 0.14),
        labels = labels(0, 0.14, 0.02),
        breaks = breaks(0, 0.14, 0.02)
    )  +
    scale_y_continuous(
        limits = (0, 150),
        labels = labels(0, 150, 30),
        breaks = breaks(0, 150, 30)
    )
)

Adding a linear regression line

fig = (
    ggplot(data.dropna(subset = ['abv'])) +
    geom_point(
        aes(x = 'abv',
            y = 'ibu',
            fill = 'ounces_str'),
        alpha = 0.5,
        color = 'black'
    ) +
    geom_smooth(
        aes(x = 'abv',
            y = 'ibu')
    ) +
    labs(
        title ='Relationship between alcoholic content (abv) and int. bittering untis (ibu)',
        x = 'abv - The alcoholic content by volume',
        y = 'ibu - International bittering units',
    ) +
    scale_fill_manual(
        name = 'Ounces',
        values = c_col) +
    scale_x_continuous(
        limits = (0, 0.14),
        labels = labels(0, 0.14, 0.02),
        breaks = breaks(0, 0.14, 0.02)
    )  +
    scale_y_continuous(
        limits = (0, 150),
        labels = labels(0, 150, 30),
        breaks = breaks(0, 150, 30)
    )
)

Faceting

fig = (
    ggplot(data.dropna(subset = ['abv'])) +
    geom_jitter(
        aes(x = 'abv',
            y = 'ibu',
            fill = 'ounces_str'),
        width = 0.0051,
        height = 5,
        color = 'black'
    ) +
    labs(
        title ='Relationship between alcoholic content (abv) and int. bittering untis (ibu)',
        x = 'abv - The alcoholic content by volume',
        y = 'ibu - International bittering units',
    ) +
    scale_fill_manual(
        guide = False,
        name = 'Ounces',
        values = c_col) +
    scale_x_continuous(
        limits = (0, 0.14),
        labels = labels(0, 0.14, 0.02),
        breaks = breaks(0, 0.14, 0.02)
    )  +
    scale_y_continuous(
        limits = (0, 150),
        labels = labels(0, 150, 30),
        breaks = breaks(0, 150, 30)
    ) +
    facet_wrap('ounces_str')
)

Heatmap

fig = (
    ggplot(data.dropna(subset = ['abv'])) +
    geom_bin2d(
        aes(x = 'abv',
            y = 'ibu')
    ) +
    labs(
        title ='Relationship between alcoholic content (abv) and int. bittering untis (ibu)',
        x = 'abv - The alcoholic content by volume',
        y = 'ibu - International bittering units',
    ) +
    scale_x_continuous(
        limits = (0, 0.14),
        labels = labels(0, 0.14, 0.02),
        breaks = breaks(0, 0.14, 0.02)
    )  +
    scale_y_continuous(
        limits = (0, 150),
        labels = labels(0, 150, 30),
        breaks = breaks(0, 150, 30)
    ) +
    theme(figure_size = (8, 8))
)

Boxplot

Generix boxplot

fig = (
    ggplot(data.dropna(subset = ['abv'])) +
    geom_boxplot(
        aes(x = 'ounces_str',
            y = 'abv')
    ) +
    labs(
        title ='Distribution of alcoholic content (abv) by size',
        x = 'size in ounces',
        y = 'abv - The alcoholic content by volume',
    ) +
    scale_y_continuous(
        limits = (0, 0.14),
        labels = labels(0, 0.14, 0.02),
        breaks = breaks(0, 0.14, 0.02)
    )
)

Violin boxplot

fig = (
    ggplot(data.dropna(subset = ['abv'])) +
    geom_violin(
        aes(x = 'ounces_str',
            y = 'abv'),
        fill = c_col[0]
    ) +
    labs(
        title ='Distribution of alcoholic content (abv) by size',
        x = 'size in ounces',
        y = 'abv - The alcoholic content by volume',
    ) +
    scale_y_continuous(
        limits = (0, 0.14),
        labels = labels(0, 0.14, 0.02),
        breaks = breaks(0, 0.14, 0.02)
    )
)

Conclusion

plotnine offers a wide range of different visualizations, which are easy to adapt for customized outputs. If you have experience with ggplot in R then a switch to plotnine is effortless.

Find more articles from me here:

  1. Learn how I plan my articles for Medium
  2. Learn how to write clean code in Python using chaining (or pipes)
  3. Learn how to analyze your LinkedIn data using R
  4. Learn how to create charts in a descriptive way in Python using grammar of graphics
  5. Learn how to set up logging in your python data science code in under 2 minutes

Gregor Scheithauer is a consultant, data scientist, and researcher. He is specialized in the topics of Process Mining, Business Process Management, and Analytics. You can connect with him on LinkedIn, Twitter, or here on Medium. Thank you!
